Product Code: PESTWB-101
Size:
| Capacity In Liters | Interior Dimension in MM | Exterior Dimension in MM | ||||
| Width | Depth | Height | Width | Depth | Height | |
| 2000 | 1700 | 800 | 1900 | 1860 | 960 | 2060 |
| 3000 | 1800 | 1000 | 1900 | 1960 | 1160 | 2060 |
| 6000 | 2000 | 1500 | 2000 | 2160 | 1660 | 2160 |
| 8000 | 2000 | 2000 | 2000 | 2160 | 2160 | 2160 |
| 10000 | 2000 | 2500 | 2000 | 2160 | 2660 | 2160 |
| 20000 | 2000 | 4000 | 2500 | 2160 | 4160 | 2660 |
| 25000 | 2500 | 4000 | 2500 | 2660 | 4160 | 2660 |
| 30000 | 2500 | 4800 | 2500 | 2660 | 4960 | 2660 |
| 35000 | 3500 | 4500 | 2500 | 3660 | 4660 | 2660 |
| 40000 | 4000 | 4000 | 2500 | 4160 | 4660 | 2600 |
| 45000 | 4000 | 4500 | 2500 | 4160 | 4660 | 2660 |
| 50000 | 4000 | 5000 | 2500 | 4160 | 5160 | 2660 |
- Wide Temperature Range: Operates between 5°C and 60°C, suitable for a variety of biological and environmental studies.
- High Temperature Accuracy: Precise temperature control with an accuracy of ± 0.2°C.
- Temperature Uniformity: Maintains a uniform temperature distribution within ± 2.0°C across the entire chamber.
- Durable Construction: Available in high-quality stainless steel or mild steel, ensuring long-lasting durability and resistance to corrosion.
- PLC-Based Control System: Advanced programmable logic controller (PLC) with a touchscreen Human Machine Interface (HMI) for easy operation and monitoring.
- CFC-Free Refrigeration System: Equipped with an environmentally friendly, CFC-free refrigeration unit for efficient cooling.
- Power Versatility: Can operate on both 230 volts and 415 volts, with support for 50/60 Hz power supply.
- Interior Lighting: Provides adequate illumination inside the chamber for better visibility during operations.
- Adjustable Trays and Racks: Comes with stainless steel trays and racks that can be adjusted to accommodate various sample sizes.
- Energy-Efficient Operation: Designed to optimize energy use, providing cost-effective and eco-friendly operation.
Technical Specification
- Walk-in BOD incubators are designed with the following features:
- Temperature Range: Operates between 5°C and 60°C.
- Temperature Precision: Offers a high accuracy level of ± 0.2°C.
- Temperature Consistency: Ensures uniformity within ± 2.0°C across the chamber.
- Construction Material: Can be constructed from either stainless steel or mild steel.
- Control Interface: Equipped with a PLC-based control system and a user-friendly touchscreen HMI.
- Refrigeration System: Utilizes an eco-friendly, CFC-free refrigeration mechanism.
- Power Requirements: Functions on 230/415 volts and 50/60 Hz electrical supply.
- Chamber Lighting: Includes adequate illumination for visibility inside the chamber.
- Storage Flexibility: Comes with adjustable stainless steel trays and racks.
- Data Logger: For continuous temperature and humidity monitoring with storage and export capabilities.
- Humidity Control System: An integrated humidity controller to maintain and regulate moisture levels inside the chamber.
- Alarm System: An audio-visual alarm for temperature deviations or system failures.
- Emergency Backup Power: Uninterruptible Power Supply (UPS) for maintaining the incubator’s function during power outages.
- UV Germicidal Lamp: For sterilization of the chamber to prevent contamination.
- Remote Monitoring: Wi-Fi or Ethernet connectivity for remote monitoring and control through a computer or smartphone.
